this document describes valueram's 1g x 64-bit (8gb) ddr3l-1600 cl11 sdram (synchronous dram), 2rx8, low voltage, memory module, based on sixteen 512m x 8-bit fbga components. the spd is programmed to jedec standard latency ddr3-1600 timing of 11-11-11 at 1.35v or 1.5v. this 204-pin sodimm uses gold contact fingers. the electrical and mechanical specifications are as follows:
features:
jedec standard 1.35v (1.28v ~ 1.45v) and 1.5v (1.425v ~1.575v) power supply
vddq = 1.35v (1.28v ~ 1.45v) and 1.5v (1.425v ~ 1.575v)
800mhz fck for 1600mb/sec/pin
8 independent internal bank
programmable cas latency: 11, 10, 9, 8, 7, 6
programmable additive latency: 0, cl - 2, or cl - 1 clock
8-bit pre-fetch
burst length: 8 (interleave without any limit, sequential with starting address Ĺ“000Âť only), 4 with tccd = 4 which does not allow seamless read or write [either on the fly using a12 or mrs]
bi-directional differential data strobe
internal(self) calibration : internal self calibration through zq pin (rzq : 240 ohm ± 1%)
on die termination using odt pin
average refresh period 7.8us at lower than tcase 85°c, 3.9us at 85°c < tcase < 95°c
asynchronous reset
pcb: height 1.18Âť (30mm), double sided component
cl (idd)
11 cycles
