• Form Factor:
  • MIcro ATX


Intel   Specifications

• Model:
  • Intel D945GPM

• Processor Support:
  • Support for an Intel ® Pentium ® D Processor in an LGA775 socket with a 1066 or 800 MHz system bus
  • Support for an Intel ® Pentium ® 4 Processor in an LGA775 socket with an 800 MHz system bus
  • Support for an Intel ® Celeron ® D Processor in an LGA775 socket with a 533 MHz system bus


• Chipset:
  • Intel ® 945G Express Chipset

• Memory:
  • Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
  • Support for 667 and 533 MHz DDR2 DIMMs
  • Support for up to 4 GB of system memory

• Expansion Slots:

  • Two PCI Conventional* bus connectors
    One PCI Express* x1 bus add-in card connector
    One PCI Express x16 bus add-in card connector


• On-Board Audio:
  • 8-channel (7.1) audio subsystem with five analog audio outputs and one S/PDIF digital audio output (optical) using the Sigmatel* 9220/9223 audio codec

• On-Board Video:
  • Intel ® Graphics Media Accelerator 950

• On-Board LAN:
  • Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel ® 82573L Gigabit Ethernet Controller
  • 10/100 Mbits/sec LAN subsystem using the Intel ® 82562GZ Platform LAN Connect (PLC) device


• Rear Panel I/O Ports:
  • Eight USB 2.0 ports
  • One serial port
  • One parallel port
  • Four Serial ATA interfaces with RAID support, (levels 0, 1, 0+1, and 5)
  • One parallel ATA IDE interface with UDMA 33, ATA-66/100 support
