MSI K9A2 Platinum Motherboard
AMD® Phenom/Athlon/Sempron in the Socket AM2+ package, AMD® 790FX chipset, 2 mazarine PCI Express x16 slots, 2 light-blue PCI Express x16 slots with x8 operations, 1 PCI Express x1, 2 PCI, DDR2, LAN, USB, IDE, SATA2, RAID, eSATA, SPDIF Optical, Firewire, Audio, RAID, ATX Form Factor |
|
- Internal I/O Interface:
- ATX 24-Pin power connector
- 4-pin ATX 12V power connector
- ATX 4-pin VGA power connector
- CPU / System FAN connectors
- Clear CMOS Jumper
- CD-in connector
- Serial port connector
- IrDA infrared module header
- Chassis intrusion switch connector
- CD-in connector
- D-Bracket2 connector
- 1 x SPDIF-out header
- 1 x IEEE1394 connector support additional 1 ports
- Front panel audio connector
- Front panel connector
- 1 x Serial port header (optional)
- 1 x VoIP card header (optional)
- 3 x USB 2.0 connector support additional 4 ports
- 1 x Floppy disk drive connector
- 6 x Serial ATA II connectors
- 1 x ATA133 HD connectors
- Rear Panel I/O Ports:
- 1 x PS/2 keyboard
- 1 x PS/2 Mouse
- 1 x Parallel port
- 1 x Serial port (COM 1)
- 1 x Optical SPDIF out
- 1 x IEEE1394 Port
- 4 x USB 2.0 Ports
- 2 x eSATA ports
- 1 x RJ 45 Port
- 6 audio jacks
- Audio:
- Chipset integrated by Realtek® ALC888/ALC888T
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec
- Form Factor:
- ATX Form Factor
- 30.5cm(L) x 24.5cm(W)
|
MSI K9A2 Platinum Motherboard
- Model:
- MSI K9A2 Platinum Motherboard
- Processor Support:
- AMD® Phenom/Athlon/Sempron in the Socket AM2+ package.
- HyperTransport 3.0 supporting speed up to 2600MHz
- Chipset:
- AMD® 790FX and SB600 Chipset
- Memory:
- DDR2 533/667/800 SDRAM (240pin/ 1.8V)
- 4 DDR2 DIMMs (8GB Max)
- Supports a maximum memory size up to 8 GB.
- Expansion Slots:
- 2 mazarine PCI Express x16 slots (PCI Express Bus SPEC V2.0 compliant; supports CrossFire Technology)
- 2 light-blue PCI Express x16 slots with x8 operations (PCI Express Bus SPEC V2.0 compliant; supports CrossFire Technology)
- When 4 PCI Express x16 slots are all installed, the PCIE x 16 lanes will auto arrange form x16/ x0/ x16/ x0 to x8/ x8/ x8/ x8
- 1 PCI Express x1 slots
- 2 PCI slots, support 3.3V/ 5V PCI bus Interface
- On-Board LAN:
- Realtek PCI-E GbLAN controller 8111B
- Integrated Fast Ethernet MAC and PHY in single chip
- Compliance with PCI-Express Bus specification v1.0a
- Supports Dual LAN 10/100/1000 Fast Ethernet by Vitesse VSC8601
- Firewire:
- Chipset integrated by VIA® VT6308P
- Transfer rate is up to 400Mbps
- Storage:
- One IDE port by AMD® SB600
- Supports Ultra DMA 66/100/133, PIO & Bus Master operation mode
- Can connect up to 2 IDE devices
- 4 SATA II ports by AMD® SB600
- 2 SATA II (5~6) ports by Promise® T3, support SAS ready devices, for storage devices only
- 2 eSATA ports by Promise® T3, for storage devices only
- Supports storage and data transfers at up to 300 MB/s
- SATA II 1~4 support RAID 0, 1 and 0+1 mode by AMD® SB600
- SATA II 5~6 & 2 eSATA ports support RAID 0, 1 and 0+1 mode by Promise® T3
- BIOS:
- The mainboard BIOS provides "Plug & Play" BIOS which detects the peripheral devices and expansion cards of the board automatically.
- The mainboard provides a Desktop Management Interface(DMI) function which records your mainboard specifications.
|
