• Storage:
  • Single channel master modes support up to two (2) IDE devices
  • Supports Ultra ATA-100/66/33 IDE drives and ATAPI compliant devices

• Rear Panel I/O Ports:
  • (1) 9-pin COM port
  • (1) 15-pin VGA port
  • Stacked PS/2 mouse & keyboard ports
  • Stacked (2) USB2.0 ports
  • (2) RJ45 10/100/1000 Base-T ports w/ activity LED

• Internal I/O Interface:
  • (1) IDE connector
  • (4) SATA ports support RAID 0, 1, 5, 10
  • (4) USB 2.0 ports (2 at rear, 2 via cable)
  • (1) COM port
  • 2x25-pin header for Tyan IPMI SMDC
  • TYAN 2 x 9 front-panel pin header

• Optional Modules:
  • M3291 , IPMI 2.0 Remote System Mgmt. Card
    - Renesas H8S2167 BMC controller
    - BT, KCS, Logging support; IPMI-over-LAN
    - Remote power on/off and reset
  • M7901/M7902, Ultra 320 SCSI TARO card
    - Adaptec AIC-7901/7902 single/dual-channel,
    - Ultra320 SCSI controller
    - Adaptec HostRAID 0, 1, 10 supported
  • M9000 SAS/SATA II TARO card
    - Adaptec AIC-9410 SAS controller
    - Support up to 4-port (M9000-5) and 8-port
    - (M9000-10 ) SAS & SATA running at 3.0Gb/s
    - Adaptec HostRAID 0, 1, & 10 supported


• System Management:
  • SMSC SCH5017, EMC6D103 & Winbond 83793G with hardware monitoring
  • Two (2) 3+1-pin CPU fan headers w/ tachometer monitoring and smart fan speed control
  • Temperature and voltage monitoring
  • Chassis intrusion header
  • Watchdog timer support

Motherboard Specifications

• Model:
  • Tyan Tempest i5000VS (S5372G2NR-LC) Motherboard

• Processor Support:
  • (2) LGA771 sockets for up to (2) Intel ® Xeon ® processors
  • 5100/5100LV/5300(80W)/5300LV series processors
  • 1066/1333MHz FSB

• Chipset:
  • Intel ® 5000V chipset (Intel ® "Blackford-VS" MCH)
  • Intel ® ESB2 South bridge
  • SMSC SCH5017 Super I/O chip

• Memory:
  • Dual memory channels
  • (6) 240-pin DDR2 FBDIMM sockets
  • Supports FBDIMM 667/533MHz
  • Supports up to 24GB of ECC memory

• Expansion Slots:
  • One 64/133 PCI-X slot in-lined with one (1) inversed PCI-E x4 slot (routed to PCI-E x8 bus)
  • One 32/33 PCI 2.3 slot
  • One x8 PCI-E slot (with PCI-E x4 bus)
  • One TYAN TARO SO-DIMM socket

• On-Board LAN:
  • Dual Gigabit MAC (ESB2 embedded) with i82563EB dual-PHY

• Integrated Video:
  • XGI Volari Z7 (XG20); PCI interface
  • 16MB DDR frame buffer of video memory


• Integrated SATA Controller:
  • One Serial ATA Host controller embedded
  • Supports four (4) ports running up to 3.0Gb/s
  • RAID 0, 1, 5, 10 supported (Windows OS only)


• Regulatory:
  • FCC Class B (Declaration of Conformity)
  • European Community CE (DoC)

• BIOS:
  • Phoenix BIOS ® on 8Mbit Flash ROM
  • Supports APM 1.2 and ACPI 1.0b
  • Serial Console Redirect; USB boot supported
  • USB boot supported
  • PnP, DMI, WfM Power Management

• Form Factor:
  • SSI CEB v1.01 footprint (12" x 10.5")
  • Onboard dual 4-phase VRM, max. 80W
  • EPS12V / SSI (24 + 8) power connectors
