ASUS M4N98TD EVO Motherboard
ASUS M4N98TD EVO Motherboard, Supports AMD AM3 Phenom II/Athlon II/Sempron
100 Series Processors, 2 PCI Slot, 2 PCI Slot X1, 2 PCI Express x16
slot, Support for SATA2, eSATA, Raid, IDE, DDR3 RAM, On Board Audio, LAN, 12 USB ports, ATX
form Factor. |
|
ASUS M4N98TD EVO Motherboard
- Rear Panel I/O Ports:
- 1 x PS/2 keyboard (purple)
- 1 x PS/2 mouse (green)
- 1 x eSATA 3Gb/s
- 1 x IEEE 1394a
- 1 x LAN (RJ45) port(s)
- 6 x USB 2.0
- 1 x Coaxial S/PDIF out
- 1 x Optical S/PDIF out
- 6 x Audio jack(s)
- Internal I/O Interface:
- 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
- 1 x IDE connector(s)
- 1 x COM port(s) connector(s)
- 5 x SATA 3Gb/s connector(s)
- 1 x IEEE 1394a connector(s)
- 1 x CPU Fan connector(s)
- 2 x Chassis Fan connector(s) (1 x 3 -pin, 1 x 4 -pin)
- 1 x Power Fan connector(s)
- 1 x S/PDIF out header(s)
- 1 x 24-pin EATX Power connector(s)
- 1 x 8-pin ATX 12V Power connector(s)
- 1 x Front panel audio connector(s) (AAFP)
- 1 x System panel(s) (Q-Connector)
- 1 x MemOK! button(s)
- 1 x Core Unlocker switch(es)
- USB Ports:
- Built-in Controller :
- 12 x USB 2.0 port(s) (6 at back panel, black, 6 at mid-board)
- Over clocking Features:
- Overclocking Protection :
ASUS C.P.R.(CPU Parameter Recall)
- Accessories:
- User's manual
- I/O Shield
- 1 x UltraDMA 133/100 cable(s)
- 4 x SATA 3Gb/s cable(s)
- 1 x SLI bridge(s)
- 1 x Q-connector(s) (2 in 1)
- On-Board LAN:
- Broadcom B5071, 1 x Gigabit LAN Controller(s), featuring AI NET2
- BIOS:
- 8 Mb Flash ROM , AMI BIOS, SPI, PnP, DMI2.0, WfM2.0, SM BIOS
2.5, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree BIOS 3
- IEEE 1394:
- VIA ® 6308P controller
- 2 x IEEE 1394a port(s)
(1 at mid-board, 1 at back panel)
- Support Disc:
- Drivers
- Anti-virus software (OEM version)
- ASUS Update
- ASUS Utilities
- Manageability:
- WOL by PME,WOR by PME,WOR by Ring,PXE
|
Motherboard Specifications
- Model:
- ASUS M4N98TD EVO Motherboard
- CPU:
- AMD AM3 Phenom II/Athlon II/Sempron 100 Series Processors
- Supports AM3 45 nm CPU
- Supports CPU up to 140 W
- System Bus:
- Up to 5.2 GT/s HyperTransport 3
- Chipset:
- Memory:
- 4 x DIMM, Max. 16GB, DDR3 2000(O.C.)/1333/1066 Hz ECC, Non-ECC,
Un-buffered Memory
- Dual Channel Memory Architecture
* Refer to www.asus.com or user manual for the Memory QVL (Qualified
Vendors Lists).
* Due to OS limitation, when installing total memory of 4GB capacity
or more, Windows ® 32-bit operation system may only recognize less
than 3GB. Install a 64-bit Windows ® OS when you want to install 4GB
or more memory on the motherboard.
* AMD AM3 100 and 200 series CPU support up to DDR3 1066MHz.
- Expansion Slots:
- 2 x PCIe 2.0 x16 (dual x16)
- 2 x PCIe x1
- 2 x PCI
- On-Board Audio:
- VIA VT1708S 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Audio Feature :
- ASUS Noise Filter
- Coaxial and Optical S/PDIF out ports at back panel
- Multi-GPU Support:
- Supports NVIDIA ® SLI Technology
- Storage:
- NVIDIA nForce ® 980a SLI ® chipset : *1
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices , navy blue
- 5 x SATA 3Gb/s port(s), blue
- 1 x eSATA 3Gb/s port(s), red
- Support Raid 0, 1, 0+1, 5, JBOD
- Special Features:
- ASUS Power Design :
8 +1 Phase Power Design
ASUS EPU
- Turbo Key
- TurboV
- Core Unlocker
- ASUS Exclusive Features :
MemOK!
Express Gate
- ASUS Quiet Thermal Solution :
Stylish Fanless Design Heat-pipe solution
Stack Cool 3 +
ASUS Fan Xpert
- ASUS Crystal Sound :
ASUS Noise Filter
- ASUS EZ DIY :
ASUS O.C. Profile
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2
Multi-language BIOS
- ASUS Q-Design :
ASUS Q-Connector
100% All High-quality Conductive Polymer Capacitors
- Form Factor:
- ATX Form Factor
- 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
|
